AOZOOM W3 AUXILIARY PROJECTOR LENS
AOZOOM W3 AUXILIARY PROJECTOR LENS
Regular price
Rs. 10,000.00
Regular price
Rs. 14,000.00
Sale price
Rs. 10,000.00
Unit price
/
per
Shipping calculated at checkout.
No reviews
Couldn't load pickup availability
- AOZOOM W3 – Key Specifications
| Feature | Detail |
|---|---|
| Model / Name | AOZOOM W3 LED Multi-Functional Dual Beam External Lamp |
| Optical Structure | Dual-Light / Dual Beam (Low + High) |
| Input Power |
Low Beam: ~ 50 W ±2 W High Beam: ~ 50 W ±2 W |
| LED Chip / Light Source | “L/3 CORE ×2” and “H/3 CORE ×2” chips, size ~ 60 × 70 mil for each core. So effectively dual cores for low and high beams. |
| Colour Temperature | 6500 K (Low beam) / 3000 K (High beam) |
| Voltage Range | 9 V – 16 V |
Extra Features / Observations
-
The lamp is described as multi-functional, meaning it supports both high and low beams in a single unit (dual beam).
-
The lower colour temp for high beam (3000K) likely gives a more yellow-tint high beam – possibly to improve visibility in adverse weather / glare control.
-
Being dual light and higher wattage, it will generate more heat; cooling / heat dissipation (heat sinks or fans) would be important, though I didn't find explicit info on the cooling system.
-
It’s meant for automotive voltage systems, and the 9-16V range makes it compatible with most 12V systems.
